LIGHTING SOLUTIONS
LED Wellglass
Description
Crompton’s energy efficient wellglass is designed for various industrial application with excellent thermal management offering durability and superior performance thereby reducing operational cost.
Features
Housing made of high pressure die cast aluminium
Ingress pritection of IP66
Luminaire efficacy of 110 Lumens/W & 130 Lumens/W
UV protected clear PC cover with option of diffused cover
Potted Driver & High Power LED
Total Harmonic Distortion <10 %
Internal surge protection of 4KV
50000 burining hours
Operating Temperature: -10 degree-50 degree
Benefits
Unique finless design aiding in lesser dust accumulation
Vertical fins for 360 degree heat dessipation
Uniform light distribution with high grade PC Cover
Sleeve provided in Eye bolt for protection against vibration
Application
Cement Industry
Power Industry
Food and Beverage Industry
Distillery Industry
Material handling Plants
Specifications
| Product Details | Wattage (W) | Voltage (V) | CCT (K) | THD | CRI |
|---|---|---|---|---|---|
| CIP-311-30-57-SL-CP-NSG | 30 | 240 | 5700 | <10% | >70 |
| CIP-311-30-30-SL-CP-NSG | 30 | 240 | 3000 | <10% | >70 |
| CIP-311-35-57-SL-CP-NSG | 35 | 240 | 5700 | <10% | >70 |
| CIP-311-35-30-SL-CP-NSG | 35 | 240 | 3000 | <10% | >70 |
| CIP-311-40-57-SL-CP-NSG | 40 | 240 | 5700 | <10% | >70 |
| CIP-311-40-30-SL-CP-NSG | 40 | 240 | 3000 | <10% | >70 |
| CIP-311-30-57-SL-DP-NSG | 30 | 240 | 5700 | <10% | >70 |
| CIP-311-35-57-SL-DP-NSG | 35 | 240 | 5700 | <10% | >70 |
| CIP-311-40-57-SL-DP-NSG | 40 | 240 | 5700 | <10% | >70 |
Highbay
Description
This Integral LED highbay luminaire comprises of die cast aluminium housing, control gear compartment, frame with toughened glass.
Features
Housing made of high pressure die cast aluminium
Ingress pritection of IP66
Luminaire efficacy of 110 Lumens/W
Diffuser made of high grade toughened glass
Potted Driver & High Power LED
Total Harmonic Distortion <10 %
Internal surge protection of 4KV with additional 10KV surge
Operating Temperature: -10 degree-50 degree
Benefits
Compact housing delivering high lumens
Separate driver compartment for ease of maintainance
Bracket and Eye bolt for flexibility in mounting
Excellent heat dessipation
Application
Warehouse
Production Areas
Power Plants
Factory workshop
Specifications
| Product Details | Wattage (W) | Voltage (V) | CCT (K) | THD | CRI |
|---|---|---|---|---|---|
| LHB-80-CDL/60-M | 80 | 240 | 5700 ANSI | <10% | >70 |
| LHB-100-CDL/60-M | 100 | 240 | 5700 ANSI | <10% | >70 |
| LHB-120-CDL/60-M | 120 | 240 | 5700 ANSI | <10% | >70 |
| LHB-140-CDL/60-M | 140 | 240 | 5700 ANSI | <10% | >70 |
| LHBN-150-CDL/60-M | 150 | 240 | 5700 ANSI | <10% | >70 |
| LHB11-180-CDL/60-M | 180 | 240 | 5700 ANSI | <10% | >70 |
| LHB11-200-CDL/60-M | 200 | 240 | 5700 ANSI | <10% | >70 |
Description
This integrated LED High bay luminaire comprises of die cast canopy, control gear housing and glass bowl. Driver and Surge protector are provided in control gear housing.
Features
Housing made of high pressure die cast aluminium
Ingress protection of IP66
Luminaire efficacy of 110, 130 & 140 lumens/W
Diffuser made of high grade toughened glass
Potted Driver & High Power LED
Total Harmonic Distortion <10 %
Internal surge protection of 4KV with additional 10KV surge
Operating Temperature: -10 degree-50 degree
Benefits
Larger surface area aiding in lesser dust accumulation
Separate driver compartment for ease of maintainance
Swirl fin structure for good air circulation aiding in great heat dessipation
Safety chain provided for additional security
Application
Warehouse
Production Areas
Power Plants
Factory workshop
Specifications
| Product Details | Wattage (W) | Voltage (V) | CCT (K) | THD | CRI |
|---|---|---|---|---|---|
| LHB11-80-CDL/60 M | 80 | 240 | 5700 ANSI | <10% | >70 |
| LHB11-80-CDL60HPM | 80 | 240 | 5700 ANSI | <10% | >70 |
| CIP-320-80-57-60D-HL5-GL-NSR | 80 | 240 | 5700 ANSI | <10% | >70 |
| CIP-320-80-57-90D-HL5-GL-NSR | 80 | 240 | 5700 ANSI | <10% | >70 |
| LHB11-100-CDL/60-M | 100 | 240 | 5700 ANSI | <10% | >70 |
| CIP-320-100-57-60D-HL4-GL-NSR | 100 | 240 | 5700 ANSI | <10% | >70 |
| CIP-320-100-57-90D-HL4-GL-NSR | 100 | 240 | 5700 ANSI | <10% | >70 |
| LHB11-100-CDL60HPM | 110 | 240 | 5700 ANSI | <10% | >70 |
| LHB11-120-CDL/60-M | 120 | 240 | 5700 ANSI | <10% | >70 |
| LHB11-120-CDL60HPM | 120 | 240 | 5700 ANSI | <10% | >70 |
| CIP-320-120-57-60D-HL4-GL-NSR | 120 | 240 | 5700 ANSI | <10% | >70 |
| CIP-320-120-57-90D-HL4-GL-NSR | 120 | 240 | 5700 ANSI | <10% | >70 |
| LHB11-140-CDL60HPM | 140 | 240 | 5700 ANSI | <10% | >70 |
| LHB11-140-CDL/60-M | 140 | 240 | 5700 ANSI | <10% | >70 |
| CIP-320-140-57-60D-HL4-GL-NSR | 140 | 240 | 5700 ANSI | <10% | >70 |
| LHB11-150-CDL/60-M | 150 | 240 | 5700 ANSI | <10% | >70 |
| LHB11-150-CDL60HPM | 150 | 240 | 5700 ANSI | <10% | >70 |
| CIP-320-150-57-60D-HL4-GL-NSR | 150 | 240 | 5700 ANSI | <10% | >70 |
Under Canopy Lights
Description
Crompton’s under-canopy lighting offers a unique combination of energy efficiency, reliability and optimised lighting solution for petrol pumps. It redefines petrol pumps into landmarks and welcoming spaces increasing customer’s sense of safety and comfort and achieving brand loyalty.
Features
Housing made of high-pressure die-cast aluminium
Ingress protection of IP66
Luminaire efficacy of 110 Lumens/W & 130 Lumens/W
Diffuser made of high grade toughened glass
Potted Driver & High Power LED
Total Harmonic Distortion <10 %
Internal surge protection of 4KV with additional 10KV surge
Available in 600x600mm frame
Operating Temperature: -10 degree-50 degree
Benefits
UV and mercury protected making the product environment friendly
Compact design for superior aesthetics
Unique heat sink for excellent thermal management
Significant energy savings with the option of 130 Lumen/W option
Application
Petrol Pumps
Toll Plaza
Railway Platforms
Billboards
Specifications
| Product Details | Wattage (W) | Voltage (V) | CCT (K) | THD | CRI |
|---|---|---|---|---|---|
| LCNP-80-CD60 HPM | 80 | 240 | 5700 ANSI | <10% | >70 |
| LCNP-80-CDL/60 M | 80 | 240 | 5700 ANSI | <10% | >70 |
| LCNP-80-CD60 HPM 600 | 80 | 240 | 5700 ANSI | <10% | >70 |
| LCNP-80-CD60 M 600 | 80 | 240 | 5700 ANSI | <10% |
>70 |
LED Street Lights
Description
Astra Neo luminaire comprises of pressure die cast aluminium housing powder coated in silver grey and toughened glass.
Features
Pressure die cast housing with toughned glass
Ingress protection of IP66
High power SMD LED’s
Luminaire efficacy of > 110 lm/W
Secondary optics for better light distribution
Potted Driver with 4KV internal surge protection
THD<10%, PF>0.95
Benefits
Efficient heat management & better light refraction
Protection against water jet & dust
Better life and improved effeciency
More light on relevant areas with less consumption
Peanut optics deliver light along & across the road to reduce zebra effect
Trouble free extended life with BIS for electrical safety
Application
Gated communities
Periphery lighting
Security lighting
Gardens
Municipal roads
Specifications
| Product Details | Wattage (W) | Voltage (V) | CCT (K) | THD | CRI | PF |
|---|---|---|---|---|---|---|
| LSTS-12-CDL & LSTS-12-CDL/NL | 12 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
| LSTS-15-CDL & LSTS-15-CDL/NL | 15 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
| LSTS-18-CDL & LSTS-18-CDL/NL | 18 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
| LSTS-25-CDL & LSTS-25-CDL/NL | 25 | 240 | 5700 ANSI | <10% | >70 |
>0.95 |
Description
Description
This streetlight luminaire comprises of die cast Aluminium housing with frame and toughened glass, pipe mounting tilt-able arrangement.
Features
Pressure die cast housing with toughned glass
Tiltable bracket
Microvent technology
Ingress protection of IP66
High power SMD LED’s
Luminaire efficacy of > 110 lm/W & 125lm/W
Secondary optics for better light distribution
Potted Driver
4KV internal + 10KV SPD
THD<10%, PF>0.95
Benefits
Efficient heat management
Flexibility to install fixtures in retrofit installation without any waste spillover
Ensures fixture performs well even when there is difference in ambient temperature
Protection against water jet & dust
Better life and improved effeciency
More light on relevant areas with less consumption
Peanut optics deliver light along & across the road to reduce zebra effect
Trouble free extended life with BIS for electrical safety
Protection against surge for improved & trouble free luminaire life
Application
Highways
City roads
Municipalities
Development authorities
Industrial develoepment corporations
Specifications
| Product Details | Wattage (W) | Voltage (V) | CCT (K) | THD | CRI | PF |
|---|---|---|---|---|---|---|
| LSTN1-170-CDL-A-M | 170 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
| LSTN1-180-CDL-A-M | 180 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
| LSTN-200-CDL-AHP-M | 200 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
| LSTN-200-CDL-A-M | 200 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
| LSTN-220-CDL-AHP-M | 220 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
| LSTN-220-CDL-A-M | 220 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
| LSTN-250-CDL-AHP-M | 250 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
| LSTN-250-CDL-A-M | 250 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
Description
HAWK II streetlight luminaire comprises of die cast Aluminium housing with frame and toughened glass,pipe mounting tiltable arrangement.
Features
Pressure die cast housing with toughned glass
Tiltable bracket
Microvent technology
Ingress protection of IP66
High power SMD LED’s
Luminaire efficacy of > 110 lm/W & 125lm/W
Secondary optics for better light distribution
Potted Driver
4KV internal + 10KV SPD
THD<10%, PF>0.95
Benefits
Efficient heat management
Flexibility to install fixtures in retrofit installation without any waste spillover
Ensures fixture performs well even when there is difference in ambient temperature
Protection against water jet & dust
Better life and improved effeciency
More light on relevant areas with less consumption
Peanut optics deliver light along & across the road to reduce zebra effect
Trouble free extended life with BIS for electrical safety
Protection against surge for improved & trouble free luminaire life
Application
Highways
City roads
Municipalities
Development authorities
Industrial develoepment corporations
Specifications
| Product Details | Wattage (W) | Voltage (V) | CCT (K) | THD | CRI | PF |
|---|---|---|---|---|---|---|
| LSTN-200-CDL-A | 200 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
| LSTN-200-WW-A | 200 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
| LSTN-220-CDL-A | 220 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
| LSTN-250-CDL-A | 250 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
Description
Nexus Neo streetlight luminaire comprises of die cast Aluminium housing powder coated in Silver grey and toughened glass.
Features
Pressure die cast housing with toughned glass
Ingress protection of IP66
High power SMD LED’s
Luminaire efficacy of > 110 lm/W & 125lm/W
Secondary optics for better light distribution
Potted Driver
4KV internal + 10KV SPD
THD<10%, PF>0.95
Benefits
Efficient heat management
Protection against water jet & dust
Better life and improved effeciency
More light on relevant areas with less consumption
Peanut optics deliver light along & across the road to reduce zebra effect
Trouble free extended life with BIS for electrical safety
Protection against surge for improved & trouble free luminaire life
Application
City roads
Industrial corridor
Municipalinties
Gram panchayats
MES
Airport authority
Specifications
| Product Details | Wattage (W) | Voltage (V) | CCT (K) | THD | CRI | PF |
|---|---|---|---|---|---|---|
| LSTP-45-CDL | 45 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
| LSTP-45-WW | 45 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
| LSTP-45-CDL-1 | 45 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
| LSTP-60-CDL | 60 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
| LSTP-60-WW | 60 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
| LSTP-72-CDL | 72 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
| LSTP-72-WW | 72 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
Description
Nexus Star Neo streetlight luminaire comprises of die cast Aluminium housing with frame and toughened glass
Features
Pressure die cast housing with toughned glass
Ingress protection of IP66
High power SMD LED’s
Luminaire efficacy of > 110 lm/W & 125lm/W
Secondary optics for better light distribution
Potted Driver
4KV internal + 10KV SPD
THD<10%, PF>0.95
Benefits
Efficient heat management
Protection against water jet & dust
Better life and improved effeciency
More light on relevant areas with less consumption
Peanut optics deliver light along & across the road to reduce zebra effect
Trouble free extended life with BIS for electrical safety
Protection against surge for improved & trouble free luminaire life
Application
Highways
City roads
Municipalities
Development authorities
Industrial develoepment corporations
Specifications
| Product Details | Wattage (W) | Voltage (V) | CCT (K) | THD | CRI | PF |
|---|---|---|---|---|---|---|
| LSTP-100-CDL | 100 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
| LSTP-100-WW | 100 | 240 | 3000 ANSI | <10% | >70 | >0.95 |
| LSTP-120-CDL | 120 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
Description
Pinnacle Neo streetlight luminaire comprises of Pressure die-cast Aluminium housing powder coated in graphite grey finish and Polycarbonate cover which gasket and fixed to the housing with screws.
Features
Pressure die cast housing with Polycarbonate diffuser
Ingress protection of IP66
High power SMD LED’s
Luminaire efficacy of > 110 lm/W
Secondary optics for better light distribution
Potted Driver with 4KV internal surge protection
THD<10%, PF>0.95
Benefits
Efficient heat management & better light refraction
Protection against water jet & dust
Better life and improved effeciency
More light on relevant areas with less consumption
Peanut optics deliver light along & across the road to reduce zebra effect
Trouble free extended life with BIS for electrical safety
Application
Gated communities
Periphery lighting
Security lighting
Gardens
Municipal roads
Specifications
| Product Details | Wattage (W) | Voltage (V) | CCT (K) | THD | CRI | PF |
|---|---|---|---|---|---|---|
| LST-18-CDL | 18 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
| LST-20-CDL | 20 | 240 | 5700 ANSI | <10% | >70 | >0.95 |
SUNRISE EFFICIENT MARKETING
Contact us at the Consulting WP office nearest to you or submit a business inquiry online.
